Introduction
The DC charging station of electric vehicles is similar to the fuel dispenser in a gas station, which can be fixed on the ground or wall, installed in public buildings (such as public buildings, shopping malls, public parking lots, etc.) and residential parking lots or charging stations. This 150 Kw DC Fast Charger can charge various types of electric vehicles according to different voltage levels.
Basic Information
Input Parameter: Rated 380V AC; 3P+N+PE; 45-65Hz
Rated Output: 150KW / 200-1000V DC; each side plug MAX 200A current output
Communication&Internet: OCPP1.6/ 2.0; Ethernet/WIFI/4G
Operating Environment:-30℃to +50℃; 5%~95% no condensation, ≤2000m
IP Level: IP54 (Indoor/Outdoor)
Protection:The 150 Kw DC Fast Charger equipment with functions: Over/Under voltage protection, Overload protection, Short circuit protection, Over/Under temperature protection, Grounding protection, Surge protection, Leakage protection...
Introduction to 150 Kw DC Fast Charger plug Interface:
The DC charging gun interface in Japan is the CHAdeMO standard, but not all Japanese cars use this DC charging port, mainly Mitsubishi and Nissan's new energy vehicles that use the CHAdeMO DC charging port.
The United States and Canada mainly use SAE J1772 standard, also known as J-plug; The American standard charging interface for DC is mainly used for AC, and a pair of high current charging holes are added below it.
The standard for DC charging interfaces of electric vehicles in the European region is IEC 62196, and the charging interfaces of DC are mainly for AC, with a pair of high current charging holes added below.
China and its neighboring countries use the GB/T20234 standard, and the GBT charging interface for DC is completely different from the design for AC.
Tips: The 150 kW DC Fast Charger can be equipped with single, dual, or even triple guns
When the charging station has two or three guns, you can freely combine different types of charging guns, which can improve the utilization rate of the charging station and charge different types of vehicles.
More details about this 150 Kw DC Fast Charger, please contact our sale team, Thank you!
